Overview
XR01CX-5N8C0 is an embedded digital refrigeration temperature controller matched with dual NTC temperature probes, designed for commercial cooling and refrigeration equipment. It runs on 230V 50/60Hz power supply with maximum power consumption of 3.5VA, featuring a wide working temperature range from 0℃ to 60℃ and applicable humidity of 20% to 85% non-condensing environment. Equipped with a clear digital display and integrated operation buttons, it supports real-time temperature viewing, parameter setting and fan output control. The built-in V13 stable program delivers precise temperature sensing and reliable switch control performance, coming with dedicated installation clips for quick panel mounting to maintain constant temperature of refrigeration equipment automatically.
Key Features
- Comes with 2pcs NTC temperature sensing probes for dual-point temperature detection
- Embedded panel installation with matched plastic mounting clips
- 230V 50/60Hz input voltage, max power consumption only 3.5VA
- Digital LED display + integrated side operation buttons for easy setup
- Independent fan output control function for refrigeration equipment
- Wide working condition: 0~60℃ ambient temp, RH 20%-85% non-condensing
- V13 optimized control program, stable operation and low failure rate
- Compact small body, saves installation space inside cooling cabinets
XR01CX-5N8C0 technical specifications table
| Parameter Item | Specification |
|---|---|
| Model | XR01CX-5N8C0 |
| Compatibility | Dual NTC temperature probes, refrigeration cooling fans |
| Working Voltage | 230 VAC 50/60Hz |
| Operating Temperature | 0 °C ~ +60 °C |
| Mounting | Panel embedded mounting with plastic clips |
| Max Power Consumption | 3.5 VA |
| Product Length | 78 mm |
| Product Width | 34 mm |
| Product Height | 60 mm |
| Product Weight | Approx. 0.14 kg |
| Country of Origin | China |
| Software Version | V13 |
| HS code | 9032.89.9000 |
| Shipping Length | 130 mm |
| Shipping Width | 80 mm |
| Shipping Height | 70 mm |
Same Series Display Models
XR01CX-5N0C0
XR02CX-5N8C0
XR03CX-5N8C0
XR04CX-5N8C0
XR06CX-5N8C0
Matching Series Controllers
CR01CX-5N8C0
XR01CX-4N1F0
XR01CX-5R0C0
Supporting System Accessories
NE9
ASC56152
Application Scope
Model XR01CX-5N8C0 is widely used in all kinds of commercial refrigeration equipment: beverage display coolers, cake fresh-keeping cabinets, supermarket refrigerated display cases, vertical small freezers, catering fresh food cooling cabinets, and mini constant temperature cold storage.
Packaging & Shipping
- Neutral safe packaging, shockproof and drop-proof protection
- Global shipping via DHL, UPS, FedEx and sea freight options
- In stock support for fast delivery
- Wholesale, retail and mixed order are acceptable
Our Service
We provide full series of refrigeration and HVAC spare parts, including control display panels, temperature controllers, sensors, power modules and industrial electrical accessories.
For technical parameters, dimension drawing, cross reference model or bulk discount, please feel free to contact us. Cick Contact us.To consult HVAC standard pls click HVAC standard.
