Name: PJEZC0H100 Digital Refrigeration Temperature Controller
SKU: PJEZC0H100
Availability: InStock

Overview

This compact digital controller PJEZC0H100 is designed for precision temperature regulation in refrigeration and HVAC systems. It supports NTC temperature probes and offers flexible relay outputs to manage compressors, fans, and defrost cycles. Built for reliable operation in demanding commercial environments, it features a clear interface, DIN rail mounting compatibility, and robust certifications for safety and performance.

Key Features

Digital precision temperature control with NTC probe compatibility
Multiple relay outputs for compressor, fan, and defrost functions
Compact form factor with DIN rail mounting capability
115V operating voltage suitable for commercial applications
Certified safety compliance for commercial refrigeration use
User-friendly interface for easy configuration and monitoring
Robust design for reliable performance in harsh environments

PJEZC0H100 Temperature Controller

technical specifications table

Parameter	Specification
Model	PJEZC0H100
Compatibility	NTC temperature probes, refrigeration & HVAC control systems
Working Voltage	115 VAC
Operating Temperature	-10 °C ~ +50 °C
Mounting	Panel mounting (DIN rail compatible with optional adapter)
Product Length	78 mm
Product Width	35 mm
Product Height	71 mm
Product Weight	Approx. 0.09 kg
Country of Origin	China (subject to production batch)
HS code	9032.89.6085
Shipping Length	150 mm
Shipping Width	100 mm
Shipping Height	80 mm

Same Series Display Models

PJEZC0H000

PJEZC0H010

PJEZC0HB00

PJEZC0H110

PJEZC0H500

PJEZC0E000

PJEZS00000

PJEZS0P000

PJEZS2P000

PJEZMNN0E0

PJEZY0H000

Matching Series Controllers

NTC030WF00

NTC030WP00

NTC030WH01

NTC030WH00

Supporting System Accessories

PZ100S00000

PZ100S00010

PZ100S00020

PZ100S00030

PZ100S00040

Application Scope

The PJEZC0H100 controller is widely applied in commercial refrigeration display cases, walk-in coolers/freezers, cold storage rooms, beverage coolers, ice machines, food service equipment, and HVAC systems requiring precise temperature control, as well as industrial cooling systems and process temperature regulation.

Packaging & Shipping

Neutral safe packaging, shockproof and drop-proof protection
Global shipping via DHL, UPS, FedEx and sea freight options
In stock support for fast delivery
Wholesale, retail and mixed order are acceptable

Our Service

We provide full series of refrigeration and HVAC spare parts, including control display panels, temperature controllers, sensors, power modules and industrial electrical accessories.

For technical parameters, dimension drawing, cross reference model or bulk discount, please feel free to contact us. Cick Contact us.To consult HVAC standard pls click HVAC standard.
