MQ-A0322G-000001 HVAC Refrigeration Solenoid Coil

Name: MQ-A0322G-000001 HVAC Refrigeration Solenoid Coil
SKU: MQ‑A0322G‑000001
Availability: InStock

Original price was: $20.00.Current price is: $10.00.

MQ-A0322G-000001 is IP67 electromagnetic coil for HVAC refrigeration solenoid valve, offering stable drive performance for refrigerant flow control.

Availability: In stock

SKU: MQ‑A0322G‑000001 Categories: Expansion Valve Drivers, Expansion Valves, Other Refrideration Accessories, Refrigeration Spare Parts Tags: AC220V electromagnetic coil, HVAC refrigeration coil, MDF valve replacement coil, MQ‑A0322G‑000001, Refrigerant control coil, Refrigeration and air conditioning accessories, Solenoid valve coil

Overview

MQ-A0322G-000001 is a high-performance IP67 electromagnetic coil specially designed for HVAC and refrigeration solenoid valves. Adopting reinforced encapsulation structure, it can resist moisture, dust and temperature fluctuations in complex refrigeration operating environments. It provides reliable driving force to open and close the refrigeration solenoid valve, precisely controlling the flow of refrigerant inside HVAC and refrigeration circuits. The coil supports independent purchase, and can also be matched with corresponding valve body as a complete solenoid valve assembly. It has stable output power, low noise and long service life, widely adapted to commercial refrigeration, air conditioning and other HVAC refrigeration scenarios.

Key Features

IP67 protection grade, dustproof and waterproof for harsh HVAC refrigeration environment
Reinforced epoxy encapsulation, good heat resistance and insulation performance
Stable electromagnetic output, reliable valve switching in refrigeration cycles
Support separate purchase of coil, flexible matching with compatible valve body
Low power consumption and low working noise for long-time continuous operation
Compact structure, easy installation and maintenance on HVAC refrigeration equipment
Wide working temperature range, adaptable to multiple refrigeration media

MQ‑A0322G‑000001 technical specifications table

Item	Specification
Model	MQ-A0322G-000001
Compatibility	MDF series refrigeration solenoid valve body
Working Voltage	AC220-240V, 50/60Hz
Operating Temperature	-40℃ ~ +80℃
Mounting	Slip-on mounting for solenoid valve
Product Length	48 mm
Product Width	42 mm
Product Height	56 mm
Product Weight	0.21 kg
Country of Origin	China
HS code	8505900090
Shipping Length	65 mm
Shipping Width	60 mm
Shipping Height	75 mm

Same Series Display Models

MQ-A03024-000001

MQ-A0311A-000001

Matching Series Controllers

MDF-A03-10H002

MDF-A03-15H002

MDF-A03-20H004

MDF-A03-22H002

MDF-B03-25H003

MDF-B03-25H004

MDF-B03-32H001

MDF-B03-32H002

MDF-B03-40H002

MDF-B03-40H004

Supporting System Accessories

DIN connector plug

Coil sealing gasket

Application Scope

The MQ‑A0322G‑000001 Solenoid Valve Coil is suitable for various HVAC and refrigeration equipment including commercial air conditioning units, cold storage refrigeration systems, heat pump units and refrigerated display cabinets. It serves as the core driving part of refrigeration solenoid valves, managing refrigerant on-off in HVAC refrigeration pipelines, and can be used in new equipment assembly or old refrigeration & HVAC system maintenance replacement.

Packaging & Shipping

Neutral safe packaging, shockproof and drop-proof protection
Global shipping via DHL, UPS, FedEx and sea freight options
In stock support for fast delivery
Wholesale, retail and mixed order are acceptable

Our Service

We provide full series of refrigeration and HVAC spare parts, including control display panels, temperature controllers, sensors, power modules and industrial electrical accessories.

For technical parameters, dimension drawing, cross reference model or bulk discount, please feel free to contact us. Cick Contact us.To consult HVAC standard pls click HVAC standard.

Should you need alternative models, kindly reach out to our team. Our company offers a comprehensive lineup of refrigeration accessories to meet diverse application demands.
